2. Contact:
Power contact:High conductivity copper alloy,partial or all gold plating
Signal contact:Phosphor bronze,partial or all gold plating

3. PCB lock:Phosphor bronze, tin plating

4. Operating Environment
Operating Temperature: -40 to 125℃ (including 40℃ temperature rise)
Relative Humidity: 95%(40℃)
Vibration: 20～500Hz, Acceleration 490m/s2
Shock: Acceleration 490m/s2

5. Main Technical Specifications
Electric characteristics
Rated current: Signal contact: 2.5A

Rated voltage: Signal contact: 60V

Rtench is a full name of Shenzhen Rongtenghui Technology Co., Ltd., which was established in 2013. It is a high-tech enterprise specializing in the research, development, production and sales of precision electronic connectors. The connector products currently designed and manufactured include POGO PIN spring connectors, test spring probes, FPC/FFC connectors, battery connectors and hardware antenna shrapnel. Wait. Products are widely used in military, medical, communications, mobile phones, security, smart watches, household appliances, walkie-talkies and railway systems, etc., the company has advanced Japanese imported CNC lathes, high-speed punching machines and Japanese Sumitomo motor injection molding machines and other production equipment and from international connections R & D and production team of the company, R & D production team average connector work experience for more than 10 years, Rong Tenghui has obtained a number of Chinese utility model technology patents and invention patents. After several years of hard work, Rong Tenghui has received support from customers such as Haier, Hisense, Panasonic, Samsung, and Tongfang.
